USB 3.1 type C to NGFF M.2 key B 2260 SSD Enclosure

Product Name:

USB 3.1 type C to NGFF M.2 key B 2260 SSD Enclosure

Number :

P-Y-03

Product Description:

USB 3.1 type C to NGFF M.2 key B 2260 SSD Enclosure

Panto Technology Co.,Ltd
P-Y-03 Specification
Model:	P-Y-03
Product Name:	USB 3.1 Type C NGFFM.2 SSD Hard Disk Enclosure
Chipset:	ASM1051
Internal interface:	female Key B NGFF(M.2)
Output interface:	female USB3.1 Type C
Data speed up to	10Gb
Material/Finish:	Aluminum with Oxidation/Sand Blasting
Product measure:	107x40x7mm
Color version:	black or silver
Product weight:	42g
Suit for SSD version:	2230/42/60mm/ NGFF Key B (M.2)
UASP:	Support
OS support:	Win8.1/8/7/VISTA/XP/MAC/Linux, (free driver)
Operating Temperature:	5℃~40℃
Storage Temperature:	~20℃~70℃
support UASP and no external power supply repuired, plug and play
Features and Specification:
Connects NGFF B Key SSD safely to computer via USB port
Compliant with PCI Express M.2 specification 1.0
Compliant with SATA 3.0 specification
Compliant with USB 3.1 specification
Supports data transfer up to 6.0Gb/s
Supports SATA-based NGFF SSD
Supports B Key NGFF SSD
Supports 2230, 2242, 2260 size NGFF SSD
Easy installation & no driver required No additional power required
Support boot function
Supports Plug & Play and Hot-Swapping
Supports any OS, like Windows, WinCE & Linux etc
Please note that it supports SATA-based B Key SSD only. It does NOT support PCI-E based B key & any M key SSD
Packing details
1.SSD Enclosure *1pcs
2.USB Cable *1pcs
3.Screwdriver*1pcs
4. Screws *2set
